Ready to Deliver
TIRATEX - The tape stretching line for highest performance
The TIRATEX is a tape extrusion and -stretching line for production of polyolefin tapes made of PP. The machine is designed for high output and best product quality such as LS tapes (Light and Strong) at high production rates and maximum energy efficiency. Modular design and several optional extras allow for an optimized execution, depending on process- and product requirements.
Showroom machine (BSW colour design) - operating time only approx. 350h
- Extruder E105 TP with THERMOCON (water temperature control unit)
Output up to 630 kg/h - Material supply station DOSITEX with gravimetric batch blending unit
1 main, 3 additive components - Screen filter with 150 mm diameter instead of 120 mm
- Special water quench design with electrical height adjustment
- Take up unit with double drying unit for high speeds
- Integrated holding unit with film cutting (incl. one extra set cutting bar) and edge trim recycling system
- Hot air oven (6 m length)
- Stretching unit for high speed operation up to 550 m/min
with 6 godets 400 mm diameter (1 unheated, 3 oil-heated, 2 watercooled) - Oil heating unit
- Tape extraction vacuum system
POLYTEX - the cost-effective tuber for the production of flat and side gusseted film tubes rewinded on rolls
The POLYTEX is suitable to produce in combination with an AD PLASTIC 2 the new innovative film valve bag AD proFilm MP. AD proFilm MP is designed for fast filling of powdery and dusty products and offers outstanding moisture protection. The new Polytex is immediately available for you and is equipped as follows:
- Mono unwind
- Intermittent slitting and embossing station
- continuous embossing station
- Strip inserter aggregate with hotmelt device
- Flat tube forming unit
- Longitudinal seam extruder
- FILMATIC S rewinder with stand displacement system for oscillation
More about Polytex
DYNASTAR - High efficiency even with short rotogravure jobs
The DYNASTAR is the gravure printing machine for short orders in flexible packaging. The DYNASTAR can be delivered directly from the W&H printing technology center in Lengerich, and is equipped with the following specifications:
- 10 high-performance printing units
- Print width 650 mm
- Print length 320 - 700 mm
- Speed 300 m/min.
- 800 mm shafted winder
- VISION-FULL, HELIOCONTROL, EASY-SYNC and VISCOCONTROL
- Deionization and ESA equipment
- PREVENTIVE MAINTENANCE
- Handling system for changing of print cylinders in DYNACART
Contact:markus.bauschulte@wuh-group.com
More about DYNASTAR
Ready to deliver - MIRAFLEX II
The MIRAFLEX product family is the most successful CI flexo printing machine on the market. Fast available for you is the new MIRAFLEX II with the following specification:
- 8 printing units
- Speed 500 m/min.
- Shafted winder, diameter 1,000 mm
- Printing width 1,270 mm
- TURBOCLEAN with VISCOCONTROL
- 2-zone drying, for natural gas source
- Equipped with VISION and EASY assistance and automation modules
- plus further equipment
More about Polytex
FILMATIC TC Winder - Innovative universal turret winder for superb roll quality
Ready to deliver is the FILMATIC TC – AUTOMATIC TURRET CAST WINDER from our technology center in Lengerich.
- Roller face width 3,100 mm
- Winding speed up to max. 450 m/min on 6'' mechanically centered winding shafts, up to diameter 1,090 mm
- Center wind with contact or gap mode
- Design package
- Chilled S-Wrap draw unit
- Slitting station for multiple ups - with or without bleed trim, max. 4 ups
- Extraction arms for reel removal, automatic shaft extraction and motorized reel removal cart
- Operator panel with PROCONTROL TS automation
- and more
More about FILMATIC
